With the development of the mobile Internet, technological progress, and the launch of high -performance and low -power processing chips, intelligent wearable devices have moved from conceptualization to commercialization, new wearable devices have continued to spread, and major technology giants have also entered the game. The development of Huaya TP-LCD single-body testing equipment is also based on the rapid development of the industry. The TP-LCD monomer testing equipment is mainly suitable for smart watches TP \ LCD defect detection, product advantages and disadvantages, and large quantities of data collection.
Equipment features
• The device is a turntable 8 -site test;
• Test information can be uploaded to meet the automation line use;
• Rotating platform design, compact size of the size;
• The smart watch LCD \ TP can be detected at the same time;
• Flexible design, testing stations can automatically fine -tune to meet multiple products.
设备参数 Equipment parameters
| Test content | Require |
| Screen Brightness & Color Uniformity | White screen[80--100]Red screen[70--100]Green Screen[70--100] Blue Screen[70--100] |
| screen color temperature | White screen[4500--5500] Red screen[1800--2200]Green screen[11000--13000]Blue screen[14400--17600] |
| Screen dead pixels, bright spots, bad lines, streaks,Smudges, black spots, light transmission, light leakage, shaving | Detection size>0.1mm |
| ALS Calibration Test | 1000lux and 200olux, color temperature 6K |
| NFC test | NFC card swipe |
